Dahua DHI-NVR2108HS-8P-4KS3 Compact 8 CH 4K PoE NVR with SMD Plus
SKU:
100% Official Brand / Serial Number Verifiable / 3-Year Warranty
Ships Same or Next Day
Over $99 Free Shipping
30-Day Returns
(HDD no included)
- Compact 8-Channel Recorder: A 260 mm-wide 1U chassis fits space-conscious surveillance installations in villas, stores and small offices.
- Eight Direct PoE Connections: Eight IEEE 802.3af/at ports carry power and video, with a shared 72 W PoE budget.
- 4-Channel SMD Plus: Recorder-side filtering distinguishes human and motor-vehicle motion from irrelevant environmental movement.
- Up to 12 MP Camera Access: Supports high-resolution IP cameras, 4K HDMI output and up to six 1080p streams at 30 fps.
- Single-Bay Local Storage: One SATA interface supports an HDD up to 20 TB for recording, playback and event review.
- Camera-Side Analytics: Compatible cameras can provide SMD and perimeter protection across all eight channels.
Dahua DHI-NVR2108HS-8P-4KS3 Compact 8 CH 4K PoE NVR with SMD Plus
Details
Compact Hardware for Focused Eight-Camera Projects
The Dahua DHI-NVR2108HS-8P-4KS3 combines eight IP camera channels, integrated PoE and local storage in a compact 260 × 232.5 × 47.6 mm enclosure. It is designed for surveillance systems in villas, retail premises and small offices where equipment space matters. All eight channels have corresponding PoE ports, allowing compatible cameras to receive power and transmit video through their Ethernet connections without a separate PoE switch.
Choose Where Intelligent Filtering Is Applied
The recorder provides four-channel SMD Plus, applying secondary filtering to distinguish human and motor-vehicle movement from activity caused by rain, leaves or changing light. For projects requiring analytics on more channels, compatible intelligent cameras can supply SMD or perimeter protection across the eight-channel system. This makes camera selection important when planning where advanced event detection will operate.
Resolution, Display and Storage Planning
- High-resolution access: Connects IP cameras up to 12 MP and outputs video through HDMI at up to 3840 × 2160.
- Conditional decoding: Handles up to six 1080p streams at 30 fps with recorder AI disabled, or four with AI enabled.
- Single-drive storage: One SATA interface supports one HDD up to 20 TB; recording duration depends on the configured bitrate, resolution and schedule.
- Audio support: One RCA input and one RCA output accommodate compatible external audio equipment.
Specification
| System | |
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
| AI | |
| AI by Recorder | SMD |
| AI by Camera | Perimeter protection; SMD |
| Perimeter Protection | |
| Perimeter Performance of AI by Camera (Number of Channels) | All channels (4 targets/s) |
| SMD Plus | |
| SMD Plus by Recorder | 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera | All channels (8 targets/s) |
| Audio and Video | |
| Access Channel | 8 channels |
| Network Bandwidth | AI disabled: 144 Mbps incoming, 144 Mbps recording and 72 Mbps outgoing AI enabled: 72 Mbps incoming, 72 Mbps recording and 36 Mbps outgoing |
| Resolution | 12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF |
| Decoding Capability | AI disabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 6-channel 1080p@30 fps AI enabled: 1-channel 8 MP@30 fps; 1-channel 6 MP@30 fps; 1-channel 5 MP@30 fps; 2-channel 4 MP@30 fps; 4-channel 1080p@30 fps |
| Video Output | 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-screen Display | 1/4/8/9 |
| Third-party Camera Access | ONVIF |
| Compression Standard | |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Audio Compression | G.711a; G.711u; PCM; G726; |
| Network | |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome; IE; Safari; Edge; Firefox |
| Recording Playback | |
| Multi-channel Playback | Up to 8 channels |
| Record Mode | General, motion detection; intelligent; alarm |
| Backup Method | USB device and network |
| Playback Mode | Instant playback; general playback; event playback; tag playback; smart playback |
| Alarm | |
| General Alarm | Motion detection; camera external alarm; PIR alarm |
| Anomaly Alarm | Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline |
| Intelligent Alarm | Perimeter protection; SMD Plus |
| Alarm Linkage | Recording; snapshot; buzzer; log; preset; email; tour |
| Port | |
| Audio Input | 1-channel RCA |
| Audio Output | 1-channel RCA |
| Alarm Input | NA (2 channels are optional) |
| Alarm Output | NA (1-channel 12 V 1 A output is optional) |
| Disk Interface | 1 SATA port. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature. |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| HDMI | 1 |
| VGA | 1 |
| Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| PoE Port | 8 ports, 10/100 Mbps, IEEE 802.3 af/at |
| General | |
| Power Supply | 53 VDC, 1.81 A |
| Power Consumption | Total output of NVR is <10 W (without HDD) Total output power of PoE is 72 W, the maximum output power of a single port is 25.5 W |
| Net Weight | 0.89 kg (1.96 lb) |
| Gross Weight | 2.05 kg (4.52 lb) |
| Product Dimensions | 260.0 mm × 232.5 mm × 47.6 mm(10.24" × 9.15" × 1.87") (W × D × H) |
| Packaging Dimensions | 374.0 mm × 119.0 mm × 311.0 mm(14.72" × 4.69" × 12.24" )(W × D × H) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH), non-condensing |
| Certifications | CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 |
