Dahua ITC413-PW4D Series Dahua Access ANPR Camera for Parking & Access Control
SKU:
Price shown is for reference only. Contact us for the final price.
Regular price
$580.00
100% Official Brand / Serial Number Verifiable / 3-Year Warranty
Ships Same or Next Day
Over $99 Free Shipping
30-Day Returns
Recognize plates. Control access. Secure your site — all in one camera.
The Dahua ITC413-PW4D is an all-in-one 4MP ANPR (Automatic Number Plate Recognition) camera powered by deep learning. It identifies vehicles, plates, brands, and colors with up to 98% accuracy (EU plates) — no extra devices or servers required.
Key Features
- High-Accuracy LPR – Recognizes plates from 120+ countries with ≥98% (EU) / ≥96% accuracy
- See in Any Light – 4MP sensor with F1.4/F1.6 mega-aperture captures 99%+ of vehicles, day or night
- Smart Vehicle Analytics – Detects vehicle brand, color, and license status instantly
- Parking-Ready – Built-in Wiegand interface and unified I/O control for barriers and electric gates
- Auto-Threat Alerts – Tri-sensor defense (light + siren + speaker) deters unauthorized vehicles
- Built to Last – IP67 weatherproof and IK10 vandal-resistant
Dahua ITC413-PW4D Series Dahua Access ANPR Camera for Parking & Access Control
Details
4MP Smart ANPR Camera for Vehicle Access Control
The Dahua DHI-ITC413-PW4D-IZ3 is a 4MP Smart ANPR camera designed for vehicle detection, license plate recognition, and entrance management. It uses a 1/1.8-inch CMOS sensor and provides 2688 × 1520 resolution. The 8–32 mm motorized varifocal lens allows installers to adjust the viewing angle and capture position according to the road, parking entrance, campus gate, or vehicle checkpoint layout.
License Plate and Vehicle Attribute Recognition
Using deep-learning algorithms, the camera can recognize license plates, unlicensed vehicles, vehicle brands, vehicle colors, and vehicle types. It supports vehicle capture speeds up to 120 km/h and provides an 8–30 m detected-width range for the DHI-ITC413-PW4D-Z3 and DHI-ITC413-PW4D-IZ3 variants. The camera also supports allowlists and blocklists with up to 110,000 records each.
IR Illumination and Active Deterrence
The IR illuminator provides up to 30 m illumination for ANPR and up to 60 m for video monitoring. Smart illumination adjusts the light intensity according to environmental brightness and vehicle movement. Intrusion and loitering detection can trigger blue and red indicator lights, audible warnings, custom audio broadcasting, and compatible external alarm devices.
Specification
| Camera | |
| Image Sensor | 1/1.8" CMOS |
| Image Resolution | 2688 × 1520 |
| Electronic Shutter Speed | Auto/Manual 1/25 s–1/100,000 s |
| Max. Detection Speed | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1:80 km/h DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3:120 km/h |
| Min. Illumination | DHI-ITC413-PW4D-Z1,DHI-ITC413-PW4D-IZ1: 0.001 Lux@F1.4 (Color, 30 IRE) 0.0002 Lux@F1.4 (B/W, 30 IRE) 0 Lux (Illuminator on) DHI-ITC413-PW4D-Z3,DHI-ITC413-PW4D-IZ3: 0.001 Lux@F1.6 (Color, 30 IRE) 0.0002 Lux@F1.6 (B/W, 30 IRE) 0 Lux (Illuminator on) |
| ROM | 4 GB |
| RAM | 1 GB |
| S/N Ratio | >56 dB |
| Scanning System | progressive scanning |
| Lens | |
| Focal Length | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1: 2.7 mm–12 mm DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3: 8 mm–32 mm |
| Field of View | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1: H: 92° (W)—46.1° (T) V: 49° (W)—26.0° (T) D: 109° (W)—52.8° (T) DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3: H: 39.9° (W)—15.1° (T) V: 21.8° (W)—8.5° (T) D: 46.6° (W)—17.4° (T) |
| Focus Control | Auto, area focus, manual |
| Number of Lens | 1 |
| Lens Type | Motorized Vari-focal |
| Max. Aperture | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1:1.4 DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3:1.6 |
| Iris Control | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1:DC-Iris DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3:P-Iris |
| DORI | |
| T: (DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1) 60.4 m (198.16 ft) |
128.7 m (422.24 ft) |
| T: (DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1) 24.2 m (79.40 ft) |
51.5 m (168.96 ft) |
| T: (DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1) 12.1 m (39.70 ft) |
25.7 m (84.32 ft) |
| T: (DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1) 6.0 m (19.68 ft) |
12.9 m (42.32 ft) |
| W: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 60.4 m (198.16 ft) |
160.0 m (524.93 ft) |
| W: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 24.2 m (79.40 ft) |
64.0 m (209.97 ft) |
| W: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 12.1 m (39.70 ft) |
32.0 m (104.99 ft) |
| W: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 6.0 m (19.68 ft) |
16.0 m (52.49 ft) |
| T: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 60.4 m (198.16 ft) |
406.9 m (1334.97 ft) |
| T: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 24.2 m (79.40 ft) |
162.8 m (534.12 ft) |
| T: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 12.1 m (39.70 ft) |
81.4 m (267.06 ft) |
| T: (DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3) 6.0 m (19.68 ft) |
40.7 m (133.53 ft) |
| Illuminator | |
| Illuminator Number | 4 |
| Illuminator On/Off Control | Auto, manual |
| Illuminator Type | DHI-ITC413-PW4D-IZ1, DHI-ITC413-PW4D-IZ3:IR (850 nm) DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-Z3:Dual Illuminators (730 nm IR/warm light) |
| Illumination Distance | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1: ANPR: 10 m (32.81 ft) Video monitoring: 30 m (98.43 ft) DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3: ANPR: 30 m (98.43 ft) Video monitoring: 60 m (196.85 ft) |
| Smart Illumination | According to the brightness of the environment, the camera automatically adjusts the intensity of its light to reveal the details of moving targets. Devices with warm light can automatically adjust the light intensity according to the time. |
| Infrared Wavelength | DHI-ITC413-PW4D-IZ1, DHI-ITC413-PW4D-IZ3:850 nm DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-Z3:730 nm |
| Video | |
| Video Resolution | Main stream: 4M (2688 × 1520)/1080p (1920 × 1080)/720p (1280 × 720) Sub stream: 720p (1280 × 720)/960H (960 × 576, 960 × 480)/D1 (704 × 576, 704 × 480)/CIF (352 × 288, 352 × 240) |
| Stream | PAL: Main stream (2688 × 1520@25 fps, 1920 × 1080@25 fps, 1280 × 720@25 fps), sub stream (1280 × 720@25 fps, 960 × 576@25 fps, 704 × 576@25 fps, 352 × 288@25 fps); NTSC: Main stream (2688 × 1520@30 fps, 1920 × 1080@30 fps, 1280 × 720@30 fps), sub stream (1280 × 720@30 fps, 960 × 480@30 fps, 704 × 408@30 fps, 352 × 240@30 fps) |
| Video Compression | H.264H; H.264B; H.264M by default; H.265; MJPEG; H.264M |
| Video Bit Rate | H.264B: 2,179 kbps–13,074 kbps H.264M: 2,179 kbps–13,074 kbps H.264H: 2,179 kbps–13,074 kbps H.265: 2,179 kbps–13,074 kbps MJPEG: 6,537 kbps–39,223 kbps |
| Scene Self-adaptation (SSA) | Yes |
| Gain Control | Manual; Auto |
| Noise Reduction | 3D NR |
| Region of Interest (RoI) | Yes, 3 |
| Image Tampering Prevention | Yes. Watermarks can be added to videos and images. The watermark can also be verified. |
| Bit Rate Control | CBR; VBR |
| Storage | Bult-in TF card port. Supports Kingston 16 G, 32 G, 128 G, 256 G; Dahua card 16 G, 32 G, 128 G, 256 G; SanDisk 16 G, 32 G, 128 G, 256 G |
| Restricted List/Trusted List | Allowlist: 110,000 Blocklist: 110,000 |
| IVS | Intrusion detection, loitering detection, up to 4 areas can be set. |
| Basic Event | Alarms for events of defocus, no storage card, storage card no space, storage card error, network disconnection, IP conflict, and illegal access. |
| Sound and Light Alarm | Yes, blue & red indicator, and supports broadcasting custom audio. |
| Alarm Linkage | Upload to FTP/Memory card, notify monitoring center, send e-mail, trigger alert output, snapshot and active deterrence |
| Capture Distance | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1: 3 m–8 m (9.84 ft–26.25 ft) DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3: 8 m–30 m (26.25 ft–98.43 ft) |
| Detected Width | DHI-ITC413-PW4D-Z1, DHI-ITC413-PW4D-IZ1: 3 m–4 m (9.84 ft–13.12 ft) DHI-ITC413-PW4D-Z3, DHI-ITC413-PW4D-IZ3: 6 m–8 m (19.69 ft–26.25 ft) |
| Network | |
| Network Protocol | HTTP; Https; 802.1x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; NTP; SFTP;DDNS; SNMP; PPPoE |
| API | Yes |
| SDK | Yes |
| Interoperability | ONVIF (Profile S/Profile T); CGI; ITSAPI; P2P |
| Management Software | DSS Pro; DSS Express; Cybercity; Smart PSS |
| Security | Username and password; MAC address; HTTPS; IEEE 802.1x; network access control |
| Browser | Plug in: IE 9, 10, 11. Chrome 52 and earlier versions Firefox 42 and earlier versions No plug in: Chrome 92 and later versions |
| Image | |
| Image Encoding Format | JPEG |
| Image Setting | Brightness; contrast; saturation; gamma; sharpness; gain; white balance |
| Day/Night | IR filter, support three modes: color/B/W/auto |
| WDR | 140 dB |
| HLC | Yes |
| BLC | Yes |
| White Balance | Auto; Regional Custom; Manual; Outdoor; Natural; Street Lamp |
| Digital Detail Enhancement (DDE) | Yes |
| OSD Overlay | Supports overlay of time; address (position of channel), lane (number/direction), plate (number and color), vehicle (speed, color, type) |
| Audio | |
| Audio Port | Yes |
| Built-in MIC | Yes; Pick-up distance: 3 m (9.84 ft), Sampling Rate: 48 k. |
| Built-in Speaker | Yes; Power: 2 W |
| Port | |
| Audio Output | 1 channel (RCA port) |
| Network Port | RJ-45 (10/100/1000 self-adaptive Ethernet Port) |
| Alarm Input | 2, optocoupler input (wet node on-off value: 5 V) |
| Alarm Output | 2, relay output (2A 30 VDC/0.5A 125 VAC), which can connect to devices such as barriers |
| RS-485 | 2 (half duplex,Transparent,DHRS,Push Data through Serial Port) |
| Reset Button | Yes |
| Wiegand | 1 channel, SHA-1 26 bit |
| Performance | |
| Maximum Number of Passed Vehicles | 10,000 |
| Max. Number of Connections | 10 |
| Intelligence | |
| AI Recognition | Recognizes vehicle types, vehicle signs, vehicle color, vehicle plate, plate, vehicle without plate. |
| Video Metadata | Displays the intelligent frame, plate and vehicle paths. |
| Vehicle Brand | Recognizes 147 vehicle logos. |
| Vehicle Color | Recognizes 12 colors: Grey, black, white, silver, blue, green, purple, red, orange, pink, brown, and yellow. |
| Vehicle Type Recognition | Recognizes 10 vehicle types: Large Bus, Heavy Truck, Medium Truck, Sedan, Van, Light Truck, Medium Bus, SUV, MPV, Pickup |
| Country and Region Supported by ANPR | Baseline support: GCC (U.A.E., Saudi Arabia, Morocco, Oman, Iraq, Egypt, Jordan, Qatar, Kuwait, Bahrain, Lebanon) Europe (Netherlands, France, Germany, Britain, Italy, Poland, Belgium, Bulgaria, Serbia, Slovakia, Spain, Denmark, Turkey, Israel, Czech Republic, Bosnia and Herzegovina, Switzerland, Austria, Hungary, Romania, Lithuania, Latvia, Sweden, Estonia, Portugal, Greece, Slovenia, Luxembourg, Palestine, Lebanon, Ireland, Finland, Norway, Croatia, North Macedonia) Russian-speaking regions (Russia, Ukraine, Kyrgyzstan, Uzbekistan, Moldova, Lithuania, Latvia, Georgia, Azerbaijan, Turkmenistan) SADC (Uruguay, Paraguay, Brazil, Argentina, Chile, Colombia, Peru, Ecuador, Guyana) North America (United States, Canada) Can be customized: Mongolia, Japan, Philippines, Vietnam, Laos, Cambodia, myanmar, Thailand, Malaysia, Singapore, Indonesia, Bangladesh, India, Pakistan, Curacao, Mexico, Guatemala, Costa Rica, Australia, New Zealand, Tunisia, Algeria, Ethiopia, Tanzania, Uganda, Equatorial Guinea, Nigeria, Zambia, Mozambique, South Africa, Mauritius |
